Hi everyone. I want to do the other half of this Revell kit.




This is an older build that I am archiving here but feel free to comment as we go along. Let's get started.


When I was way younger I saw this car run. I was maybe 12 or 13 at the time. TV Tommy Ivo came to Bremerton Raceway and made exhibition passes. 3 times this car went down the strip, 3 times the chute came out and 3 times I cheered until I was hoarse. In those days they didn't have slipper clutches so you had to spin the tires. That's why these old dragster's smoked the tires for almost the whole 1/4 mile. Then I went to one of the Beach Bingo movies and there the car was with a Buick Special Station Wagon body on it. Ugly thought I but what a cool car.

The reason for the multi-engine cars was simple. NHRA had ban Nitro Methane. So it was gas only. The common thought was the way to go faster was put more engines in it. Tommy Ivo also had a dragster with 2 Buick's in it that was called the Twin Mill. The Freight train was one of the most successful dragsters ever campaigned and it only had 2 engines. This car was a handful to keep going straight. It was really like 2 power trains. 2 V-16 engines driving a differential. The V8 engines were hooked together to make the v-16 concept. The two on the left drove the front wheels and the 2 on the right drove the rear wheels. 2 clutches one for each end.

So with all that said it's off to the build.


Here is the mock up on the frame. You can see how big the frame tubes are. Had to be to handle the weight and the torque.



I started this build and then went every which away. I went ahead and painted the body. It can be curing while I put the engine together.



I had the frame done so I went ahead and painted that and set it aside.



Went and got a can of Dulpi-color Buick Red paint and started on the engines. Built the long blocks and then did the paint.





That gets it started. All comments and question are welcome. Thanks for looking in.
